FIRE DRAGONFLY ToPeFPV version - Lightweight and Fast Cinema Drone Frame

99.00

KEY FEATURES:

  • two versions: with 4.6 mm thick “Artisan” Full Woven arms or 8 mm thick Regular Hybrid arms

  • up to 75 degrees for DVR camera positioning

  • compact and narrow main body design

  • adjustable HD camera mount

  • regular and “toilet tank” battery accommodation

  • arms interlocking anti-wobbling feature

Arms version:
Quantity:
Pre-Order

IMPORTANT NOTICE:

Collecting pre-orders till 31.07.2018. Next batch production date is 14.08.2019.

Additional 3d printed canopies and accessories are available for order or free download here.

Main specifications and features:

  • Smashed X type frame

  • 235 mm MTM

  • 95/ 115 grams weight including hardware (4.6 mm thick/ 8 mm thick arms)

  • 22 mm high main stack, 15/ 10 mm high rest of body (4.6 mm thick/ 8 mm thick arms)

  • 30.5x30.5 and 20x20 main stack mounting and 20x20 stack in the back

  • 5 inch props

  • Micro and Mini sized cams

  • 25-75 deg. rotation angle for DVR camera




Description:

FIRE DRAGONFLY ToPeFPV version is made in collaboration with Tomass Petersons aka ToPeFPV - one of the best pilots in Northern Europe, who have proven his skills by winning many podiums around globe.

The frame was developed around idea of extremely lightweight and compact platform with high camera positioning angle. That allows to take cinematic footage with higher speeds than regular freestyle drone.

Frame is offered with two types of arms: 4.6 mm thick “Artisan” Full woven or 8 mm thick 3k Plain/ UD CF composite arms. First type is more lightweight, second is more durable.

Battery on top of the frame can be installed in regular or in perpendicular position, as "toilet tank".

Arms are interlocking and fixed with 5 screws per pair. That solution is keeping them firm together and eliminates any wobbling.

Bottom plate has place for main stack with 20 and 30.5 mm holes layout. Additionally in the back is arranged secondary 20x20 stack for fixation of VTX plate .

All plates and arms have chamfered edge, they are nice to touch and safe for wires.

Top and bottom plates are mounted with countersunk screws. That makes surface flat and allows easy and unobstructed mounting of battery.

Camera holding plates are with holes for universal adjustable HD cam protection pod, specially designed for use on most of CrissCrossFPV frames.

Frame is developed within CrissCrossFPV's "Light Weight - Low Drag" concept.

Top materials used only, see details below.

Happy flying!!!

Main package:

  • 4x 8 mm thick arm made from Toray T700 3k Plain Full Woven CF sheet with high gloss finishing

  • 1x 2 mm thick top plate made from Toray T700 3k Plan/ UD CF sheet with high gloss finishing

  • 2x 2 mm thick middle plate made from Toray T700 3k Plan/ UD CF sheet with high gloss finishing

  • 2x 2 mm thick camera plate made from Toray T700 3k Plan/ UD CF sheet with high gloss finishing

  • 1x 3 mm thick bottom plate made from Toray T700 3k Plan/ UD CF sheet with high gloss finishing

  • 4x 10 mm long 7075 T6 Aluminium standoff

  • 1x set of steel hardware

Bonus accessories included:

  • 2x 20x220mm Polyester battery straps with non-slip silicone layer

  • 1x low ESR Rubycon 35V 1500uF capacitor

  • 1x set of anti-damping o-rings with long nylon screws for stack

  • 1x set of Carbon steel motor screws

Recommended FPV drone building parts:

  • 22xx/ 23xx/ 24xx sized motors

  • FuriousFPV Racepit 30.5x30.5 Flight Controller

  • Aikon AK32 4-in-1 55A 6S 30.5x30.5 4in1 ESC

  • Foxeer Falcor 1200TVL

  • TBS Unify EVO

  • TBS Crossfire Nano Rx
